Record and author compliant, professional Blu-ray discs without a PC with this all-in-one HD combo deck. Recordings from a camcorder can be easily transferred to a high definition disc, or down-converted and recorded onto a standard DVD. Copying unprotected DVD and Blu-ray discs is a simple process with a built-in duplication function. USB 2.0 and i.Link connectors, combined with an SD/SDHC memory card slot provide an interface to most SD and HD digital camcorders.
General |
|
Power
requirement |
AC 120 V,
60 Hz |
|
Power
consumption on/off |
34 W/3.0
W |
|
Temperature |
|
|
Operating |
41°F
to 95°F (5°C to 35°C) |
|
Storage |
-4°F
to 140°F (-20°C to 60°C) |
|
Operating
position |
Horizontal
only |
|
Dimensions
(W x H x D) |
- 17-1/10"
x 2-6/8" x 13-13/16"
-
(435 mm x
70 mm x 351 mm)
|
|
Weight |
11.2 lbs
(5.1 kg) |
|
Input
and Output* |
|
Video
input/output |
1 Vp-p,
75 (BNC) |
|
Audio
input/output |
2Vrms
(pin jack) |
|
S-video
input/output |
Y: 1.0
Vp-p, 75 , C: 0.286 Vp-p, 75 |
|
DV input |
4-pin for
DV, HDV IN |
|
Remote
input |
3.5 mm
diameter jack |
|
Serial
command |
D-sub
9-pin
|
|
Component
video output |
- Y: 1.0
Vp-p, 75
-
CB/CR,
PB/PR: 0.7 Vp-p, 75
|
|
HDMI
output |
19-pin
type A (Deep Color, x.v.Color, Ver.1.3a) |
|
USB
terminal |
USB2.0 |
|
Digital Audio Output
|
EIAJ Optical (Toslink) |
|
SD
Memory Card |
|
Compatible
SD memory card |
SD, SDHC |
|
HDD
Deck |
|
Storage
capacity |
500GB |
|
Video
recording compression system |
MPEG-2
(VBR), H.264/AVC |
|
Audio
recording system |
- Dolby
Digital (2ch),
-
Linear PCM
(2ch, XP mode only)
|
|
BD/DVD
Deck |
|
Video
recording compression system |
MPEG-2
(CBR/VBR), H.264/AVC |
|
Audio
recording system |
- Dolby
Digital (2ch),
-
Linear PCM
(2ch, XP mode only)
|
|
Region
code |
- BD:
Region A
-
DVD: #1
|
|
Accessories |
|
Supplied
accessories |
- AC
power cord, audio/video cable,
-
BNC male to
RCA female adapter,
-
infrared
remote control unit, “AA” battery x 2
|
1 Year Limited Warranty
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Built-in professional Blu-ray Recorder
- Internal 500GB hard disk for editing, duplicating
- Create professional BDMV (with menu) or BDAV format discs
- Stores up to 24 hours of HD (AE mode using dual-layer 50GB disc)
- Supports BD-R or BD-RE (erasable) Blu-ray discs.
- Authors discs with auto-start or repeat playback
- Digital and analog inputs for wide compatibility
- USB — (connect to camcorder)
- SDHC card — (AVCHD, ProHD* camcorder)
- i.Link — (HDV, DV camcorder)
- Composite/S-Video input — (Analog SD device, camcorder, etc.)
- Flexible monitoring via HDMI, component output
- RS-232C terminal for external control
*ProHD Camcorder files supported in SP (19/25Mbps) modes only.
|
|
|
|
|
|
|
|
